Safe Working Load - 200kg
Base Length - 1150mm
External Base Width Closed - 700mm
External Base Width Open - 1130mm
Internal Base Width Closed - 600mm
Internal Base Width Open - 1030mm
Base Width Adjustment - Electric
Under Bed Clearance - 130mm
Minimum Height Yoke - 300mm
Maximum Height Yoke - 1920mm
Average Lift Range* - 1620mm
Lifter Weight - 46kg
Minimum Storage Height - 1350mm
Under Base Height - 55mm
Maximum Hoist Reach - 1060mm
Minimum Hoist Reach - 610mm
Hoist Reach at Maximum Height - 515mm
Mass of Heaviest Part - 24kg (Mast assembly)
