Patient Surface Width - 900mm
Patient Surface Length - 2000mm | 2200mm
Length Extension - 200mm
Overall Width (includes side surround) - 1020mm
Overall Length (includes Head and Foot boards) - 2170mm | 2370mm
Low Height - 184mm
High Height - 760mm
Safe Working Load - 250kg
Backrest Range - 0-65Degrees
Knee Bend Range - 0-32 Degrees
Trendelenburg Range - +_ 12 Degrees
Backrest length - 770mm
Fixed section (auto-regression back up/down) - 280mm
Upper leg Section - 340mm
Lower leg Section - 660mm
