Specifications

Code - BD4610
Compliant with standard IEC 60601-2-52
Warranty - 10 Years Frame, 3 Years Electrics

Mattress Surface Dimensions
Width - 889mm
Length - 2032mm (extendable to max 2134mm)

Overall External Dimensions
Overall Length (including bumpers) - 2240mm
Overall Extended Length - 2340 - 2490mm
Overall Width (siderails down) - 1000mm
Overall Width (siderails up) - 1030mm

Height Range
Low with 127mm dual casters - 254mm
High with 127mm dual casters - 762mm
Low with 127mm single casters - 292mm
High with 127mm single casters - 800mm

Weight Capacity
Safe Working Load - 272kg
Max Patient Weight - 207kg

Product Code: BD4610

Features

Exceptional low height to reduce falls risk
Full 125mm under bed clearance from head to foot end
4 corner bumpers
CPR release handle
Patient control lockout
Flat deck for ease of cleaning
Backrest angle indicator
One handed slow release head and foot end side rails
Forward and reverse Trendelenburg
Boostless™ backrest system and backrest angle indicator
4 x 125mm dual central locking castors
Integrated 3 stage 250mm length extension
Integrated nurse controls on footboard and exterior of head end side rails
Integrated patient controls on interior of head end side rails
Seamless smooth surfaces maximising infection control
Optional USB power outlets to plug in mobile devices
Open architecture to simplify cleaning and mattress installation
Under bed clearance for lift and overbed table compatibility
