Code	KE1620
Overall Size	880 mm (W) × 1130 mm (L), extending to 1800 mm when fully flat
Mattress Size	1800 mm (L) × 750 mm (W) with 500 mm seat depth
Mattress Construction	100 mm premium 4-layer foam mattress with welded pressure-relieving cover
Height Range	480 mm to 860 mm with lie-flat, forward tilt, and reverse tilt functionality
SWL	400kg
Backrest Adjustment	0° to 85° with CPR emergency quick release
Trendelenburg	15° head-down and foot-down tilt
Castors	150 mm precision twin-wheel castors with centre steering
Wheelbase	330 mm high × 1400 mm long
Castors	590 mm (W) × 750 mm (L)
Undercarriage Clearance	140mm

Designed specifically for Endoscopy and Colonscopy procedures, providing enhanced patient access and clinical efficiency
Unique twin dropside system allow clinicians to lower one section while maintaining critical patient support
Wide-format design provides increased patient comfort and improved procedural access
Full chair-to-flat positioning with independent backrest and leg-rest adjustment
Forward and reverse tilt positioning, including Trendelenburg functionality
Ultra-low entry height improves patient safety during transfers
Class-leading 400kg Safe Working Load (SWL)
Long-life rechargeable battery system for reliable cordless operation
Premium 4-layer pressure-relieving mattress enhances patient comfort
CPR emergency quick-release backrest mechanism
Fold-away transport handles and centre steering for excellent manoeuvrability
Smooth, gap-free design supports infection control and easy cleaning
