Patient Surface Width: 900mm
Patient Surface Length: 2000mm | 2200mm
Length Extension: 200mm
Overall Width (includes side surround): 1020mm
Overall Length (includes Head and Foot boards): 2170mm | 2370mm
Low Height: 110mm
High Height: 740mm
Safe Working Load: 200kg
Backrest Range: 0-70 Degrees
Knee Bend Range: 0-36 Degrees
Trendelenburg Range: +-12 Degrees
Backrest Length: 880mm
Fixed Section (auto-regression back up/down): 310mm(up) 180mm(down)
Upper Leg Section: 330mm
Lower Leg Section: 530mm(standard) 730mm(extended)
